What is a Molex connector used for?

Power Supply Connectors These “Molex” connectors bring DC power to the drives inside a PC case. The large one on the right is used for disk, CD-ROM and DVD drives, while the small connector is used for floppy drives and other devices.

How does a Molex connector work?

Molex connectors come in thousands of sizes and shapes, but the most common style utilizes a pin-and-socket interconnect: Four independent pieces join a single wire to another wire. The pin―a metal clamp of sorts―is crimped to the wire of choice using a specialized crimping tool.

How do I identify a Molex connector?

The Molex connector is one where the male/female terminology is a bit odd. The female connector is usually found on the end of a cable, and it slips inside of a plastic shell which surrounds the male pins on the male connector.

How many Molex connectors does a PSU have?

Yes, from the product page you can see that it includes support for up to 6 molex connectors.

Why are Molex connectors used in computers?

Several connector types have become established for connecting power in desktop PCs because of the simplicity, reliability, flexibility, and low cost of the Molex design. Certain Molex connectors are used for providing power to the motherboard, fans, floppy disk drive, CD/DVD drive, video card, some older hard drive models, and more. Compatible connectors are available from many manufacturers, not just Molex and AMP.

How many pins are typical Molex connector?

4 pin peripheral power connector: This connector is commonly referred to as molex connector. 4 pin peripheral to SATA cable Assembly. 6 Pin PCI Express Power Connector.4 Pin ATX +12V Power Connector. SATA power connector. 8 Pin PCI Express Power Connector.

What are Molex cables used for?

Molex cables are primarily used for power-supply units, or to connect power-supply units to hard drives, as with the Molex-to-SATA power cable shown below.

What is the purpose of a Molex cable?

Molex is the name of the company who develops computer and other related connectors and products. This term is also known as the Molex power connector, which is the connector shown in the picture and is what connects your computer power supply to drives and devices inside the computer. Almost all devices inside your computer use a molex connector.
